Introducing the Mondraker Raze Carbon RR Trail Bike in Flame Red, a precision-engineered marvel designed to conquer any trail with style and speed. Crafted with the most advanced materials and cutting-edge technology, this bike is ready to elevate your riding experience to new heights.
At the heart of the Raze Carbon RR is its Raze 29 Stealth Air full Carbon frame, featuring the innovative Zero Suspension System with 130mm of travel. This, combined with Forward Geometry, ensures unmatched control and agility on challenging terrain. Boost 12x148mm rear axle and Enduro MAX sealed bearings provide durability and stability, while the HHG internal cable routing maintains a sleek, clean look.
Choose from a range of sizes to find your perfect fit: S, M, L, or XL, each meticulously crafted for optimal performance. Paired with a Fox Float Factory Kashima EVOL rear shock and Fox 36 29 Float GRIP2 Factory Kashima fork, you'll enjoy a plush, responsive ride with customizable settings for your preferences.
The components of the Raze Carbon RR are nothing short of exceptional. From the Acros custom headset to the Onoff Krypton Carbon handlebar and Fox Transfer Factory Kashima seatpost, every detail is designed for maximum performance and comfort. Grips by Onoff provide a secure hold, while the Fizik Vento Argo X5 saddle ensures comfort on long rides.
Bringing you to a controlled stop are Sram Level Bronze Stealth brakes with 4-piston callipers and Centerline rotors, while the Mavic CrossMax XL S rims and Maxxis tires provide reliable traction and durability.
Powering your ride is a Sram X0 Eagle T-Type crankset paired with a Sram GX Eagle AXS rear derailleur and shift levers, offering smooth and precise shifting across the 12-speed cassette.
Weighing in at just 13.4 kg, the Mondraker Raze Carbon RR Trail Bike is impressively lightweight without compromising strength or performance. Whether you're tackling technical descents or grinding up steep climbs, this bike is your ultimate companion for conquering the trails around Liverpool and beyond. Experience the thrill of riding like never before with the Mondraker Raze Carbon RR.
Specification:
Frame:
Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors.
Sizes:
S: 380mm / M: 420mm / L: 450mm / XL: 500mm
Rear shock:
Fox Float Factory Kashima EVOL, 205x57.5mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Shock settings:
Light compression, light rebound, air volume spacer 0.6
Fork:
Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offsete. Settings: high and low-speed compression, high and low-speed rebound, air preload
Headset:
Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
Stem:
Onoff Krypton FG 30mm, CNC, 31.8mm barbore
Handlebar:
Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips:
Onoff Desert, 1lock-on, 135mm
Seatpost:
Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L size: 475.1x175mm, XL size size: 475.1x200mm
Saddle:
Fizik Vento Argo X5
Front brake:
Sram Level Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake:
Sram Level Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever:
Sram Level Bronze, tools-free reach adjust, lever pivot bushings
Rims:
Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes
Spokes:
Mavic 24 straight-pull double butted spokes
Front hub:
Mavic Infinity hub, Boost 15x110mm, IS 6 bolts
Rear hub:
Mavic Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, XD freehub
Front tire:
Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear tire:
Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Crankset:
Sram X0 Eagle T-Type, Boost, DUB axle, Direct mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL55
Rings:
32T, CNC-machined alloy, T-Type
Chain:
Sram GX Eagle T-Type, 12s, Powerlock
Rear derailleur:
Sram GX Eagle AXS, T-Type roller bearing clutch, cage lock, 1x12s
Shift levers:
Sram Eagle AXS Pod MMX, 12s
Cassette:
Sram XS-1275, 10-52T, T-Type, 12s
Weight:
13.4 kg
