Mondraker Crafty Carbon R 2025 Electric Mountain Bike - Bunker Grey

Mondraker Crafty Carbon R 2025 Electric Mountain Bike - Bunker Grey

Save 0%

£6,294 ~~£6,299~~

Select an option to add this to your cart.

Take your trail riding to the next level with the 2025 Mondraker Crafty Carbon R – a cutting-edge electric mountain bike built for speed, control, and all-day adventure. Finished in sleek Bunker Grey, this high-performance e-MTB blends lightweight carbon engineering with Bosch’s latest Performance Line CX Smart System, giving you seamless power, superior handling, and relentless capability on even the toughest terrain.

Power Meets Precision

Equipped with a Bosch Performance Line CX motor (25km/h limit) and a massive 800Wh Powertube battery, the Crafty Carbon R provides extended range and consistent power delivery for the longest rides. The Bosch Mini Remote & System Controller ensure intuitive operation, allowing you to adjust assistance levels effortlessly while keeping your focus on the trail.

Advanced Suspension for Total Control

Fox 38 Float GRIP Performance Fork (160mm travel) – e-bike tuned for ultimate stability on technical descents.
Fox Float-X LV Performance Rear Shock (150mm travel) – providing plush responsiveness and maximum traction.
Updated Zero Suspension System – Mondraker’s industry-leading design absorbs hits efficiently while maintaining pedalling efficiency.

Precision Handling & Confidence-Inspiring Geometry

Forward Geometry – longer reach, optimised weight distribution, and improved stability on steep descents.
Crafty Stealth Air Carbon Frame – lightweight yet ultra-durable for aggressive riding.
Boost Axle Spacing (12x148mm Rear & 15x110mm Front) – ensuring stiffness and responsiveness.
Mavic E-Deemax 29” Wheels – paired with Maxxis Minion DHF/DHR II tubeless-ready tyres for unbeatable grip.

Top-Tier Shimano XT Drivetrain & Brakes

Shimano XT M8100 12-speed groupset – ultra-smooth shifting with a wide 10-51T cassette.
Shimano XT M8120 4-piston brakes – paired with 203mm ICE-Tech rotors for unmatched stopping power.

Designed for Maximum Versatility

Onoff Pija Dropper Post – adjust saddle height on-the-fly for technical terrain.
Ergon SM-10 Saddle & Onoff Forest Lock-On Grips – comfort and control for all-day riding.
HHG Internal Cable Routing – keeps cables protected for a clean and sleek look.

Dominate Any Trail with the Mondraker Crafty Carbon R 2025

Whether you're charging up climbs, shredding descents, or pushing the limits on technical terrain, the Crafty Carbon R delivers an electrifying ride like no other. Available now at The Rolling Fix, Liverpool – gear up and experience next-level e-MTB performance today!

Specifications

Frame: Crafty Stealth Air full Carbon front triangle, Stealth Alloy rear triangle, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Sizes: S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

Rear shock: Fox Float-X LV Performance, 185x55mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

Shock settings: CS40 compression, RL60 rebound, Rezi B40, LML, 0.2 volume spacer

Fork: Fox 38 29 Float GRIP Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload

Headset: Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock

Stem: Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore

Handlebar: Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.

Grips: Onoff Forest, CNC lock-on, 135mm

Seatpost: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)

Saddle: Ergon SM-10

Front brake: Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin

Rear brake: Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin

Brake lever: Shimano XT M8100, ergonomic antiskid lever with servo wave, tool less reach adjust, free stroke adjust

Rims: Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes: Mavic J-bend double butted, contactless lacing

Front hub: Mavic, Boost 15x110mm, IS 6 bolts

Rear hub: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, MS freehub

Front tire: Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Rear tire: Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Crankset: Race Face Aeffect-R ebike, 160mm

Rings: Race Face, 34T, steel, direct mount

Chain: Shimano XT M8100, 12s

Rear derailleur: Shimano XT M8100, SGS, Shadow+

Shift levers: Shimano XT M8100, Rapid Fire Plus, 12s

Cassette: Shimano XT M8100 10-51T Hyperglide+, 12s

Derailleur hanger: Sram UDH

Weight: 23,9 kg

Display: Purion 400 / Bosch Mini Remote / Bosch System Controller

Motor: New Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)

Battery: Bosch Powertube 800Wh
