Mondraker Chaser Electric Mountain Bike - Fog Grey
Description
Introducing the Mondraker Chaser Electric Mountain Bike in captivating Fog Grey, now available at our Liverpool store! Engineered to conquer any trail with ease, this e-bike seamlessly blends cutting-edge technology with superior performance, delivering an exhilarating ride like no other.
Crafted with a Chaser 6061 Alloy Stealth Evo frame, this bike boasts the e-Bike Optimized Zero Suspension System with 150mm travel, ensuring a smooth and controlled ride over rough terrain. Its Forward Geometry provides enhanced stability and control, while the internal removable battery offers convenience and a sleek appearance.
Available in a range of sizes from S to XL, every rider can experience the perfect fit and comfort for their adventures. Paired with a RockShox Deluxe Select R DebonAir rear shock and RockShox 35 Silver TK 29 fork, you'll enjoy exceptional suspension performance tailored to your preferences.
Equipped with a powerful Bosch Performance Line CX Cruise motor and a long-lasting Bosch Powertube 625Wh battery, this bike offers incredible range and reliable assistance on every ride. Whether you're tackling steep climbs or cruising along flat trails, the Mondraker Chaser ensures effortless pedaling and exhilarating speed.
Designed for maximum control, the Sram DB8 brakes provide reliable stopping power, while the Sram SX Eagle drivetrain offers smooth and precise shifting through 12 gears. With Mavic E-CrossRide rims, Maxxis Rekon tires, and a Race Face Aeffect ebike crankset, this bike delivers unrivaled performance and durability.
Complete with a Bosch Intuvia display and a comfortable MDK ebike saddle, the Mondraker Chaser Electric Mountain Bike is ready to elevate your off-road adventures. Don't miss your chance to experience the thrill of riding this exceptional e-bike – visit our Liverpool store today and take your cycling adventures to new heights!
Specifications
Frame:
Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard
Sizes:
S: 380mm / M: 420mm / L: 450mm / XL: 490mm
Rear shock:
RockShox Deluxe Select R DebonAir, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
Shock settings:
Light compression, Linear rebound, 1 Token
Fork:
RockShox 35 Silver TK 29, 160mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset:
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem:
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar:
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips:
Onoff Twin, 1lock-on, 135mm
Seatpost:
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
Saddle:
MDK ebike black
Front brake:
Sram DB8, 4-piston calliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake:
Sram DB8, 4-piston calliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever:
Sram DB8, tool reach adjust, lever pivot bushings
Rims:
Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes:
Mavic J-bend double butted, contactless lacing
Front hub:
Mavic, Boost 15x110mm, IS 6 bolts
Rear hub:
Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire:
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Rear tire:
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Crankset:
Race Face Aeffect ebike, 165mm
Rings:
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain:
Sram SX Eagle, 12s, Powerlock
Rear derailleur:
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers:
Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
Cassette:
Sram PG-1210, 11-50T, 12s
Derailleur hanger:
Mondraker M068
Weight:
25.4 kg
Display:
Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
Motor:
Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM
Battery:
Bosch Powertube 625Wh
